3650-10

All vinyl construction assures durability and flexibility in all weather conditions. Long lasting brilliant fluorescent color, provides high visibility protection. Ultraviolet stabilized color provides maximum resistance to fading. Colors available: Safety-Orange and Lime Green High density base creates low center of gravity for maximum stability. Engineered to meet MUTCD and NCHRP-350 specifications. Options such as custom stenciling and reflective 3M™ collars are available.

MODEL NUMBER 3650-10
COLOR
MATERIAL One Piece Construction All PVC ConeBase - Black Base - White Underline, Colored Top Coat, Highly Pigmented PVC - UV Stabilzed
HEIGHT 36 in
WEIGHT 10 lb 4.54 Kilogram
DIMENSION A 2.75 in
DIMENSION B 10.5 in
DIMENSION C 15.25 in
WALL THICKNESS TOP 0.075 in
WALL THICKNESS BOTTOM 0.130 in
TENSILE STRENGTH 1200 psi min
Elongation 200% min
TEAR STRENGTH 250 lbs/inch min
HARDNESS 75 +/- 5 Shore A

***Weights & dimensions are nominal. Specifications are subject to change without notice.

MODEL NUMBER 3650-10
COLOR
MATERIAL One Piece Construction All PVC ConeBase - Black Base - White Underline, Colored Top Coat, Highly Pigmented PVC - UV Stabilzed
HEIGHT 36 in
WEIGHT 10 lb 4.54 Kilogram
DIMENSION A 2.75 in
DIMENSION B 10.5 in
DIMENSION C 15.25 in
WALL THICKNESS TOP 0.075 in
WALL THICKNESS BOTTOM 0.130 in
TENSILE STRENGTH 1200 psi min
Elongation 200% min
TEAR STRENGTH 250 lbs/inch min
HARDNESS 75 +/- 5 Shore A

***Weights & dimensions are nominal. Specifications are subject to change without notice.
