CUSTOM PLASTISOL FORMULATIONS

Since 1972, Lakeside Plastics, Inc. has been a leading provider of custom plastisol formulations for customers in a range of industries. Our experts offer individual consultations to create solutions specific to customer demands, with customizable color, texture, and finish options. Other properties incorporated into our formulas include dielectric strength, resistance to weather, abrasion, chemical attack, fire, and UV light. Our plastisols are custom formulated for dip coating, rotational molding, slush molding, open form molding and knife coating. Available physical property ranges include but are not limited to tensile strength from 750 to 3000 psi; elongation capabilities of 100% to 500%; 10 to 97 Shore A hardness; and viscosity levels between 250 to 50,000 cps using the Brookfield Viscometer. We handle volumes from 5 gallons to the truckload, with weights per gallon varying from 8.5 to 13 pounds.

All products are comprehensively tested at our state-of-the-art, ISO 9001:2015 certified facility to ensure the highest industry standards for quality and integrity are met. We offer cost-effective pricing with the shortest lead times in the industry. Custom compounding and toll compounding services are also available. For more information about our custom plastisol formulations or the other value-added capabilities we offer please see the table below or contact us directly.

+
General Capabilities
  • Custom Compounding
  • Toll Compounding
  • Custom Development of Formulation
  • Custom Colors
  • Consult
  • Technical Service Assistance
Applications
  • Dip Coating
  • Molding
  • Rotational Molding
  • Slush Molding
  • Knife Coating
  • Open Molding
  • Hot Melt Castings
Resistances(Typical Properties but not Limited to)
  • Chemical Attack
  • Weather
  • UV Light
  • Dielectric Strength
  • Fire Resistance
  • Abrasion Resistance
Tensile 750 - 3000 psi
Elongation 100 - 500%>
Hardness 10 - 97 Shore A
Viscosity 250 - 50000 cps #6 spindle, 20 rpm at 80℉
Weight/Gallon 8.5 - 13 Lbs.
Quality Fully Staffed Lab
Testing Testing Facilities Available to Meet Industry Standards
Timeline Shortest Lead Times in Industry
Volume 5 gallon to Truck Load
+
Markets
  • Automotive Plastisol
  • Mil - Spec Plastisol
  • Tool Coatings
  • Plating Racks
  • Industrial Fabrics
  • Boots/Footware
  • Mats
  • Filters
  • Fishing Lures
  • Textile
  • Outdoor Structures
  • Industrial Belting
  • Electrical Plastisol
  • Radio Opaque Plastisol
  • Third Party Requirements
  • UL
  • NSF
Industry Standards
  • ISO 9001:2015
  • CPSIA Compliant
  • Bio Based
  • UL
  • NSF
  • Mil-Spec
  • Non Phthalate
  • REACH
  • RoHS
