All vinyl construction assures durability and flexibility in all weather conditions.
Long lasting brilliant fluorescent color, provides high visibility protection.
Ultraviolet stabilized color provides maximum resistance to fading.
Colors available: Safety-Orange, Pink, Lime Green, Blue, Yellow, and White.
High density base creates low center of gravity for maximum stability.
Engineered to meet MUTCD and NCHRP-350 specifications.
Options such as custom stenciling and 3M reflective collars are available
| MODEL NUMBER |
1850-00 |
| COLOR |
|
| MATERIAL |
One Piece Construction All PVC ConeBase - Black Base - White Underline, Colored Top Coat, Highly Pigmented PVC - UV Stabilzed |
| HEIGHT |
18 in
|
| WEIGHT |
3 lb
1.36 Kilogram
|
| DIMENSION A |
2.19 in
|
| DIMENSION B |
7.25 in
|
| DIMENSION C |
11.5 in
|
| WALL THICKNESS TOP |
0.065 in
|
| WALL THICKNESS BOTTOM |
0.120 in
|
| TENSILE STRENGTH |
1200 psi min |
| Elongation |
200% min |
| TEAR STRENGTH |
250 lbs/inch min |
| HARDNESS |
75 +/- 5 Shore A
|
***Weights & dimensions are nominal. Specifications are subject to change without notice.
