All vinyl construction assures durability and flexibility in all weather conditions.
Long lasting brilliant fluorescent color, provides high visibility protection.
Ultraviolet stabilized color provides maximum resistance to fading.
Colors available: Safety-Orange and Lime Green.
High density base creates low center of gravity for maximum stability.
Engineered to meet MUTCD and NCHRP-350 specifications.
Options such as custom stenciling and reflective 3M™ collars are available.
| MODEL NUMBER |
2825-05 |
| COLOR |
|
| MATERIAL |
One Piece Construction All PVC ConeBase - Black Base - White Underline, Orange Top Coat, Highly Pigmented PVC - UV Stabilzed |
| HEIGHT |
28 in
|
| WEIGHT |
5 lb
2.27 Kilogram
|
| DIMENSION A |
1.75 in
|
| DIMENSION B |
7.5 in
|
| DIMENSION C |
13 in
|
| WALL THICKNESS TOP |
0.075 in
|
| WALL THICKNESS BOTTOM |
0.130 in
|
| TENSILE STRENGTH |
1200 psi min |
| Elongation |
200% min |
| TEAR STRENGTH |
250 lbs/inch min |
| HARDNESS |
75 +/- 5 Shore A
|
***Weights & dimensions are nominal. Specifications are subject to change without notice.
